Control, operation
Operating instructions
Installation and removal of attachment parts
Raise the safety lever. Disconnect hydraulic hose 11, hydraulic hose 12 and, if present, hydraulic hoses 13 and 14 from the pipes on the stick. Close off open lines immediately to prevent dirt infiltration. Support the grapple so that it is stable. Remove the plate 6 and carefully knock out pin 4. If necessary, start the engine and raise the attachment slightly.
3.5.5 3.5.5.1
Mechanical quick change adapter (option) Safety instructions and removal of working tools. Move the attachment as slowly as possible when installing or removing a working tool. Familiarize yourself with the operating principle of the quick change adapter before installing or removing any working tools. the ground as possible when locking and unlocking to avoid dangerous movements. stand on the working tool or attachment. e machine operator must ensure that the locking pins for the quick change adapter are inserted in the proper bore holes on the working tool and that the working tool is attached properly. Check visually to ensure that the working tool is tightly seated. e tool, but only lift the tool to the point where the seating can be checked, for example the pin in the pin eye, by curling the bucket in and out. to ensure it is still seated tightly. ck change adapter or the integrated load hook can exceed or fall below the load carrying capacity of the carrier machine. During operation, make sure that the values given in the load chart and the technical data of the carrier machine are adhered to.
3.5.5.2
Overview
Fig. 3-70
3 - 70
Mechanical quick change adapter
