Control, operation
Operating instructions
Installation and removal of attachment parts
3.5.2
Safe removal and installation of attachment pins lling device to push out the pins on the attachment. held by another person. of the pin and hit the screw only. first to the stop, then install the castle nut by hand until contact and tighten it only to the point where the cotter pin can be installed.
3.5.3
Installation and removal of digging tool
Fig. 3-68
Installation and removal of digging tools
The following is a description of the installation and removal of digging tools. Digging tools include backhoe bucket, ditch cleaning buckets or ripper.
3.5.3.1
Removing the digging tool Position the attachment in such a way that the entire bottom part of the digging tool is laying on the ground. Unscrew the locking plate 5 and remove the locking plate 6 and knock out pin 3 and pin 4.
