Control, operation
Operating instructions
Working with the machine
Fig. 3-66
Height and side adjustable boom
To adjust the height of the boom: Move switch S241 to position 0. The indicator light H196 does not light up. Push the foot pedal k down. The adjustable boom cylinder will be extended, i.e. the attachment moves up. Push down foot pedal m. The adjustable boom cylinder will be retracted, i.e. the attachment moves down. To adjust boom to side: Press switch S241 in position 1 (center position). The indicator light H196 lights up. Push the foot pedal k down. The boom is turned to the right. Push down foot pedal m. The boom is turned to the left.
Accessory kit AHS 12 and changeover spool available This variation is required if an attachment such as a hydraulic hammer or a scrap cutter is to be operated in addition to the adjustable boom.
3 - 62
MJFCIFSS
A 316 Litronic / 8720369
