RT9150E OPERATOR MANUAL Item
Description
OPERATING CONTROLS AND PROCEDURES Graphic
Explanation You can display the lifting capacity tables for all permissible telescoping statuses: Enter the desired telescoping status (1) with the F9 to F13 buttons (2). The corresponding Load Chart (2) is displayed.
3
11
Telescope status input, F9-F13
4 1
2
In the event of impermissible telescoping statuses, all values in the Load Chart will be 0. To display the permissible working range for the entered RCL code and telescope status or all permissible telescope statuses, press the F8 button (4) to open the working range submenu. Refer to Working Range Submenu, page 3-96.
3
Grove
Published 2-18-2016, Control # 614-00
3-95
