RT9150E OPERATOR MANUAL Item
Description
OPERATING CONTROLS AND PROCEDURES Graphic
Explanation • Start Input mode: press the F2 button (1) once, symbol turns green • Input mode on: press either the F5
2
button or the F6 button once, to bring up the next outrigger configuration(2):
Enter outrigger span, F2
100%, full extend 50%, mid-extend. Refer to Outrigger Deployment, page 3-82. • Start Input mode: press the F3 button (1) once, symbol turns green • Input mode on: press either the F5
3
button or the F6 button once, to bring up the next permissible swing range (4):
Enter swing range, F3
(1) 360° swing range (2) Working position 0° to the rear * (3) Working position 180° to the front * * Swing gear must be off. Refer to Swing Range, page 3-83. • Start Input mode: For main hoist: press the F4 button (4) until symbol (1) is green For auxiliary hoist: press the F4 button (4) until symbol (2) is green
4
• Input mode on: press either the F5
Enter reeving, F4
button
or the F6 button
once:
To change reeving by one line (3) and display the relevant maximum load (5) for that reeving. Refer to Entering the Reeving, page 383.
5
Grove
Maximum load in tons (t) or kilo pounds (klbs) for displayed RCL code.
Maximum load display
Refer to the RCL Monitoring Submenu, page 3-86 for more information.
Published 2-18-2016, Control # 614-00
3-79
3
