RT9150E OPERATOR MANUAL Item
Description
OPERATING CONTROLS AND PROCEDURES Graphic
Explanation When Input mode is activated: • To the right: increases the value
10
Entering values
• To the left: reduces the value Slow turning changes the value slowly. Fast turning changes the value fast. • On: Machine Shutdown, buzzer sounds
11
Degree of utilisation about 100% or an error exists.
RCL shutdown
• Off: No shutdown Refer to RCL Shutdown, page 3-72. The lamp (1) lights up. In the Rigging mode submenu: Press button once, rigging mode monitoring submenu opens. 12
Input confirmation
3
In the Rigging mode monitoring submenu: Press button once, rigging mode is accepted, Monitoring submenu opens, lamp (1) goes out.
1
Either Item 2 or 5
Grove
Published 2-18-2016, Control # 614-00
3-71
