OPERATING CONTROLS AND PROCEDURES
RT9150E OPERATOR MANUAL
SETTINGS SUBMENU Press the settings submenu button (Figure 3-47) in the main menu to open this submenu. FIGURE 3-47
Settings Submenu Item 1
5
2
6 10
9
7
3 11
4
8
FIGURE 3-48
Description
1
Outrigger control graphic
2
Setting control lever characteristics
3
Setting the display brightness
4
Telescoping emergency program access
5
Lamp test
6
Operating hours submenu
7
Critical load control, on/off
8
Current telescoping mechanism status display
9
Telescoping cylinder hydraulic pressure
10
Swing gear hydraulic pressure
11
Hydraulic circuit pressure
Refer to the following table for a description of each item listed above. Item
1
3-52
Description
Graphic
Outrigger control graphic
Explanation
No function.
Published 2-18-2016, Control # 614-00
