RT9150E OPERATOR MANUAL
OPERATING CONTROLS AND PROCEDURES
MONITORING SUBMENU The Monitoring submenu shows the most important measured values. Press the monitoring submenu button (Figure 3-40) in the main menu to open the submenu.
FIGURE 3-40
Monitoring Submenu Item 1
2
3
4
5
6
Description
1
Hydraulic oil temperature, in °C (°F)
2
Battery voltage, in Volts
3
Coolant temperature, in °C (°F)
4
Fuel supply, as a percentage
5
Engine speed, in RPM
6
Transmission oil temperature, in °C (°F)
With the monitoring submenu open, the indicated values are displayed. The color of the bar indicates the following:
FIGURE 3-41
Grove
3
•
Green: Value OK
•
Yellow: Limit value almost reached
•
Red: Maximum limit value exceeded or minimum value not reached, refer to Warning Messages, page 3-62.
