S6.2 6131 Hydraulic Filter Assembly
Version no
000
T-code
395/396/397/398/399
1. Hydraulic Filter 1.1. Removal NOTE!
It is recommended that hydraulic fluid be drained from hydraulic tank prior to replacing filter.
1. Lower carriage fully to ensure all hydraulic pressure is relieved. 2. Turn key switch OFF, and disconnect battery connector from the truck. 3. Remove dash (see page 100). 4. Remove blue cover on filter adapter collar. Filter is attached to the bottom of the blue cover. 5. Remove filter by pulling straight down to snap it out of latch.
1.2. Installation 1. Snap filter onto blue cover. 2. Install cap and filter assembly in hydraulic tank. 3. Test operate truck. 4. Check hydraulic fluid level and refill as needed. 5. Replace dash. 6. Connect battery connector to the truck. 7. Return to service.
