S6.1 6112 Hydraulic Tank
Version no
000
C-code
T-code
395/396/397/398/399
1. Removal 1. Lower carriage fully and retract reach mechanism fully. 2. Remove dash (see page 100). 3. Drain hydraulic system (see page 448). 4. Remove left side panel (see page 102). 5. Turn the key switch OFF and disconnect battery connector from the truck. 6. Remove drive motor and brake assembly. 7. Remove pump and motor. 8. Disconnect hydraulic hose to mast. Plug ends to prevent contamination. 9. Disconnect hydraulic hose to control valve. Plug end to prevent contamination. 10. To remove reservoir, tilt truck end of reservoir up. Pull reservoir back, away from mast. Once the front of reservoir has cleared front truck frame, lift the reservoir out. 11. Remove hydraulic filter adapter.
