BT Electric Electrical Stand-Up Rider Truck RRX35/45 RDX30 RSX40/50 Master Service Manual 306756-000

Page 385

F-code

PS Version no

001

Section

C-code

S5.15 5710 Main Electronic Card T-code

395/396/397/398/399

1. Remove the main electronic card panel. 2. Raise fork carriage so that it is visible from the operator compartment. 3. Locate RV2 trim pot on the main electronic card. The RV2 trim pot will be above the right corner of the #4 electrical connector. NOTE!

The RV2 trim pot is a 270 degree turn pot. Over turning the pot can cause damage to the Pot.

4. Turn RV2 Trim Pot fully clockwise. NOTE!

The adjustment must be performed each time the main electronic card is replaced.

5. While standing on the brake pedal switch, move the lift/lower lever 0.0787 inch (2 mm) towards lower. Adjust the RV2 trim pot so the fork carriage will begin to lower.

10. Adjustment Procedures for Setting Brake Switch and Brake Transducer 1. Remove cover panel from main electronic card. 2. Remove floor plate. NOTE!

To determine the software version on the truck, turn the key switch ON. Software version is shown on the dash display at the initial power up.

3. Go into programming mode (see page 401). Note the current parameter settings.

© BT Prime-Mover, Inc.

Return

Set parameter 12 at 4

Set parameter 15 at 50 (P5-04 and P5-05); 16 at 50 (P5-06 and P5-07)

Master Service Manual

2001-10-31

383
