PS S4.0 4110 Steering Arm / Wheel / Lever Version no
001
T-code
395/396/397/398/399
3. Steering Tach 3.1. Removal 1. Park truck on level surface 2. Turn key switch to OFF and disconnect battery at battery connector and securely block truck. 3. Remove control pod. 4. Remove screws (28) and remove lower control pod panel (1). 5. Remove steering wheel (10). 6. Loose setscrew (25) and remove coupler (26). 7. Electrically disconnect steering tach motor (17) wires from wiring harness. Remove four screws (31) holding tach motor (17).
3.2. Installation 1. Install steering tach motor (17) and secure with four screws (31). 2. Connect steering tach motor (17) wires from wiring harness. 3. Install coupler (26) and tighten set screw (25). 4. Install steering wheel (10). 5. Install lower control pod panel (1) and tighten screws (28). 6. Install control pod.
