PS S4.0 4110 Steering Arm / Wheel / Lever Version no
T-code
001
395/396/397/398/399
2. Steering Wheel 2.1. Removal 1. Park truck on level surface. 2. Turn key switch to OFF and disconnect battery at battery connector and securely block truck. 3. Remove control pod. 4. Remove screws (28) on lower control pod panel (1) and remove panel. 5. Remove four screws (16). 6. Remove steering wheel (10). Inspect and replace bearing as needed.
2.2. Installation 1. Install steering wheel (10) in upper control pod panel (2). 2. Align holes on steering wheel mount and install four screws (16). Check steering wheel for ease of turning. 3. Install lower control pod panel (1) and install screws (28). 4. Install control pod. 5. Connect battery connector to the truck. Turn key switch to ON. 6. Test operation of steering wheel (10) and truck.
218
