F-code
Section
C-code
PS S4.0 4110 Steering Arm / Wheel / Lever Version no
001
T-code
395/396/397/398/399
1. Control Pod 1.1. Removal 1. Park truck on level surface. 2. Turn key switch to OFF and disconnect battery connector from the truck. Block truck. 3. Remove dash retaining screws (see page 100). 4. Remove adjusting lever (23) and washer (27). 5. Lift pod assembly. 6. Lift dash approximately 6 inch (152.4 mm) to access controls pod's wiring harness connectors. 7. Disconnect harness and remove control pod.
1.2. Installation 1. Route control pod wiring harness through dash. 2. Connect control pod harness to truck’s main wiring harness. 3. Install adjusting lever (23) and washer (27). 4. Install dash.
© BT Prime-Mover, Inc.
Return
Master Service Manual
2000-08-04
217
