PS S3.6 3550 Load Wheels, Sizes 4 X 3, 5 X 4, and 5 X 3 Version no
T-code
000
398/399
2. Installation 1. Pack bearings with grease. 2. Install bearings in the load wheel. 3. Install load wheel assembly in toe box (2). NOTE!
Place a block behind the axle to hold it in place while assembling the rocker plate and snap rings.
4. Install axle (1), washers (6 and 7) and rocker plate (3). 5. Install retainer rings (4) to axle (1). 6. Remove the blocking. Lower truck to the floor. 7. Connect battery connector to the truck. 8. Test operate truck. 9. Return truck to service.
