PS S3.6 3550 Load Wheels, Sizes 4 X 3, 5 X 4, and 5 X 3 Version no
000
T-code
398/399
1. Removal 1. Park the truck on a flat surface. 2. Lower carriage fully. 3. Turn key switch to OFF and disconnect battery connector from the truck. Check to make sure the battery retainer plates are in place. WARNING Block all wheels to prevent truck from rolling. 4. Hoist truck so load wheels are approximately 2 inches (50.8 mm) off the floor and securely block. 5. Remove retainer ring (4) from the axles. 6. Drive the axle back out through the wheels. Remove rocker plate (3). Remove two washers (6 and 7) on each side of the wheel. Axle (1) is welded into the rocker plate. Remove the load wheel (9) from the toe box (2). 7. Inspect bearings (8).
