BT Electric Electrical Stand-Up Rider Truck RRX35/45 RDX30 RSX40/50 Master Service Manual 306756-000

F-code

Section

C-code

PS S3.2 3540 Non-Braking Caster Wheel, RRX35/RSX40 Version no

002

T-code

395/398

2. Thrust Bearing 2.1. Removal 1. Park the truck on a flat surface.

2. Turn key switch to OFF and disconnect battery at battery connector. Check to make sure battery retainer plates are in place.

3. Jack the rear of the truck.

4. Remove main electronic card panel.

5. Remove floor board.

NOTE!

For models with brake on caster wheels, remove brake arm.

6. Bend tab down on lockwasher (2).

7. Remove locknut (1), lockwasher (2) and Nilos ring (3).

8. Inspect and replace bearings as needed.

© BT Prime-Mover, Inc.

Return

Master Service Manual

2000-08-04

193
