7. Wheel Bolt 1. Drain transmission oil by removing drain plug (28). 2. Remove transmission from truck. 3. Remove drive axle from the transmission case. 4. Press or drive out the damaged bolt from the drive axle rim. NOTE!
Always install a new drive axle seal during assembly.
5. Smooth away any burring around the bolt hole. Press or drive new bolt into place. 6. Install drive axle into the transmission case. 7. Install transmission on truck.
