F-code
Section
C-code
PS S2.0 Transmission
2550
Version no
T-code
000
395/396/397/398/399
5. Axle Sealing Ring Replace the axle sealing ring when there is oil leakage from the drive axle.
5.1. Disassembly 1. Drain transmission oil by removing drain plug (28). Remove copper washer (18) from drain plug. 2. Remove transmission page 155).
from
the
truck
(see
3. Remove bolts (34) from lower case cover (37). Remove lower case cover (37). Remove O-ring (15) from cover. 4. Loosen drive axle bolts (16). Remove bolts (16) and keeper washer (36). 5. Drive out the drive axle (17). NOTE!
To avoid bearing damaging during removal, use a split bearing puller.
6. Using a puller, remove bearing (23) from drive axle (17). NOTE!
The seal ring (26) may remain in the transmission case (38).
7. Remove seal ring (26) transmission case (38).
174
Return
Master Service Manual
from
axle
(17)
or
2002-01-09
