Removing the LCD Brackets and FPC Cable 1. See “Removing the LCD Panel” on page 81. 2. Turn the LCD panel over to expose the rear.
3. Lift the adhesive protector and disconnect the cable from the LCD Panel.
4. Lift the FPC cable from the panel. 5. Remove the eight securing screws (four on each side) from the LCD Panel brackets.
Step LCD Brackets
Size M2*3
Quantity
Screw Type
8
6. Remove the LCD brackets by pulling away from the LCD Panel.
82
Chapter 3
