Removing the LCD Bezel 1. See “Removing the LCD Module” on page 60. 2. Remove the two upper and two lower bezel screw caps and screws.
Step LCD Bezel
Size M2.5*6
Quantity
Screw Type
4
3.
Starting from the lower left side of the bezel, pry the bezel upwards and away from the panel. Move along the top and right until all sides of the bezel are removed. NOTE: If necessary, use a pry to lift up the outside edges of the bezel.
78
Chapter 3
