Boot This menu allows the user to decide the order of boot devices to load the operating system. Bootable devices includes the USB diskette drives, the onboard hard disk drive and the DVD drive in the module bay.
Information
Main
PhoenixBIOS Setup Utility Advanced Security Power Boot
Exit Item Specific Help
Boot priority order: 1. IDE0 : WDC WD1600BEVT-22ZCT0-(S1) 2. IDE1 : HL-DT-STDVDRAM GT10N-(S3) 3. Network Boot : Realtek Boot Agent 4. USB HDD : 5. USB FDD : 6. USB KEY : 7. USB CD/DVD ROM :
F1 Help Esc Exit
30
↑↓ Select Item ←→ Select Menu
F5/F6 Change Values Enter Select XSub-Menu
Use < ↑ > or < ↓ > to select a device, then press <F6> to move it up the list, or <F5> to move it down the list. Press <Esc> to escape the menu.
F9 Setup Defaults F10 Save and Exit
Chapter 2
