Advanced The Advanced screen allows the user to configure the various advanced BIOS options. IMPORTANT:Making incorrect settings to items on these pages may cause the system to malfunction. Unless you have experience adjusting these items, we recommend that you leave these settings at the default values. If making settings to items on these pages causes your system to malfunction or prevents the system from booting, open BIOS and choose Load Optimal Defaults in the Exit menu to boot up normally.
Information
Main
Advanced
PhoenixBIOS Setup Utility Security Power Boot
Exit Item Specific Help
XPnP Configuration XVideo Display Configuration XAdvanced Chipset Control
Additional setup menus to configure PCI devices
PS/2 Mouse IDE Controller: On chip SATA SATA Mode: SATA Smbus Interface
[Enabled] [Disabled] [Enabled] [IDE AHCI] [Enabled]
USB Host Controller: Legacy USB Support: Option ROM Placement
[Enabled] [Enabled] [Disabled]
Gigabit Lan Network Boot:
[Enabled] [Enabled]
Large Disk Access Mode: Installed O/S: Reset Configuration Data: Processor Assisted Virtualization:
[DOS] [Other] [No] [Enabled]
F1 Help Esc Exit
↑↓ Select Item ←→ Select Menu
F5/F6 Change Values Enter Select XSub-Menu
F9 Setup Defaults F10 Save and Exit
The table below describes the items, menus, and submenus in this screen. Settings in boldface are the default and suggested parameter settings. Parameter PnP Configuration
Description Enter the PnP Configuration menu.
Submenu Items • • •
24
Palette Snooping PCI/PNP ISA UMB Region Exclusion PCI/PNP ISA IRQ Resource Exclusion
Video Display Configuration
Enter the Video Display Configuration menu.
• • •
ATIF ACPI Methods Video Display Devices Video Expansion
Advanced Chipset Control
Enter the Advanced Chipset Control menu.
• • •
Advanced NB Options Advanced SB Options TriCore Down Core
