Bottom View
Item
140
Description
Item
Description
JCPU1
CPU Socket
JSATA1
HDD Connector
JCRT1
CRT Connector
JSATA2
ODD Connector
JDIMM1
Memory DIMM1 Connector
PJP1
AC-IN Connector
JDIMM2
Memory DIMM2 Connector
PJP2
Battery Connector
JHP1
Head-Phone Connector
SW9
Wireless SWITCH
JMIC1
MIC-In Jack
U39
North Bridge
JMINI1
Wireless Card Connector
JUSB1
USB Connector
JP20
FAN1 Connector
JUSB2
USB Connector
JRJ-45
RJ45 Connector
