Replacing the Speaker Modules 1. Place the left and right speaker modules in the chassis as shown.
2. Replace the two securing screws. NOTE: The left and right speaker module securing screws differ slightly in length. Ensure the correct screw is used for each speaker. • •
Left Speaker Module (red callout): M2.5*3 Right Speaker Module (green callout): M2.5*6
3. Run the speaker cabling along the front of the casing as shown and replace the adhesive strips.
