Maintenance and servicing work 3.23 Lubrication work on the axles Caution! In order to avoid damage to the lubrication points, use only lithium-saponified brand-name grease!
Lubricating the rear axle Notice! The machine has an oscillation-type rear axle. Lubricate the bearing every 20 service hours at the latest. A
Lubricate the oscillation-type bearing as follows: • Park the machine on level ground • Retract all hydraulic rams • Stop the engine and remove the ignition key • Apply the parking brake • Lubricate grease nipple A of the oscillation-type bearing
Fig. 55: Grease nipples for oscillation-type bearing
Lubricating the front and rear axle planetary drive bearings
B
Lubricate the planetary drive bearing as follows: • Park the machine on level ground • Retract all hydraulic rams • Stop the engine and remove the ignition key • Apply the parking brake • Lubricate grease nipples B (2 x) on each planetary drive bearing
Fig. 56: Grease nipples on planetary drive bearings
3-38
Serv-HB 34900/01 – Edition 1.0 * 34901_0320_Wartung.fm
