Rotating beacon (option

26 4

3

2

1 5

25 24 6 7 8

23 22 21 20 19 9 10 11 12 13

14

15 16 18 17 16 15

1.1 Machine outside view

Pos. Description

1 Bracket for warning stripe (option) 2 Headlights with turn indicators 3 Radio aerial (option) 4 Left/right rearview mirrors 5 Front working light (option) 6 Protective FOPS screen (option) 7 4 eye hooks for removing the cab1

8 Door arrester 9 Rear left working light 10 Rotating beacon (option) 11 Backup warning system (option) 12 Numberplate bracket with light (option) 13 Rear right working light (option) 14 Engine cover lock 15 Turn indicator/brake/rear lights and reflectors 16 Rear hooks for loading/tying down the machine (left/right) 17 Quickhitch couplers for additional control circuit (option) 18 Towing gear2 or automatic trailer coupling (option) 19 Handle 20 Socket for hydraulic oil preheater (option) 21 Safety strut for loader unit 22 Wheel chock 23 Bracket for numberplate and warning stripe (option) 24 Hooks for loading/tying down the machine at front of frame (left/right) 25 Front towing gear2 26 Front-edge protection

1. Eye hooks are for removing the cab only, and may not be used for crane handling the machine. 2. Not certified as a trailer coupling and for loading or tying down the machine.
