Maintenance and servicing work 3.12 Washer system tank Refilling washer fluid Tank filler inlet 1 is located in the cab to the left of the seat. 1 MAX MIN
Notice! Fill with clean tap water only! Add a suitable cleaning agent if required. In winter: add antifreeze for washer systems to the water. Refer to the antifreeze instructions for further information on concentrations.
Fig. 30: Tank for washer system
3.13 Engine and hydraulics cooling system Safety instructions regarding cooling system maintenance The combined water/oil cooler is located in the engine compartment. It cools both the diesel engine and the hydraulic oil of the drive and work hydraulics.
Danger! The cooling system is hot and under high pressure! Never open the coolant tank or drain coolant if the diesel engine is hot!
☞ Wait at least 10 minutes after stopping the diesel engine, then open the Fig. 31: Label: hot surface
filler cap to the first notch and release the pressure – see Filling up coolant on page 3-20 ☞ Wear protective gloves and clothing
Danger! Danger of swallowing antifreeze when handling it!
☞ Seek medical attention immediately if antifreeze has been swallowed ☞ Keep antifreeze out of reach of children
Information on inspection and cleaning work on the cooling system Dirt on the radiator fins reduces the radiator’s heat dissipation capacity! • Check the radiator once a day for dirt and clean it if necessary. Refer to the maintenance plan for the intervals • In dusty or dirty work conditions, clean more frequently than indicated in the maintenance plan • An insufficient coolant level reduces the heat dissipation capacity and can lead to engine damage! • Check the coolant level at regular intervals. Refer to the maintenance plan for the intervals – see Maintenance plan overview on page 3-5 • If the coolant must be replace frequently, have the cooling system checked for leaks by an authorised workshop!
Serv-HB 34900/01 – Edition 1.0 * 34901_0320_Wartung.fm
3-17
