Maintenance and servicing work ☞ Start the engine and let it run briefly at low speed ☞ Stop the engine • Wait a moment until all the oil has run into the oil sump
☞ Check the oil level again • Fill up if necessary and check again
☞ Completely remove all oil spills from the engine
Environment! Use a suitable container to collect the engine oil as it drains and dispose of it in an environmentally friendly manner!
3.10 Washer system tank Refilling washer fluid Tank filler inlet 1 is located in the cab to the left of the seat. 1 MAX MIN
Notice! Fill with clean tap water only! Add a suitable cleaning agent if required. In winter: add antifreeze for washer systems to the water. Refer to the antifreeze instructions for further information on concentrations.
Fig. 25: Tank for washer system
Serv-HB 34900/01 – Edition 1.0 * 34901_0320_Wartung.fm
3-15
