Maintenance and servicing work Filling up engine oil Caution! Too much or incorrect engine oil can result in engine damage! Do not add engine oil above the MAX mark of the oil dipstick A Use only the specified engine oil – see Fluids and lubricants on page 3-4
B
Environment! Use a suitable container to collect the engine oil as it drains and dispose of it in an environmentally friendly manner! max min
Fill up the engine oil as follows: • Clean the area around oil filler cap B with a lint-free cloth • Open filler cap B • Pull out oil dipstick A and wipe it with a lint-free cloth • Fill in engine oil • Wait a moment until all the oil has run into the oil sump • Check the oil level with oil dipstick A – see Checking the engine oil level on page 313 • Fill up oil if necessary and check the oil level again
A
Fig. 23: Filling up engine oil
Close filler cap B and completely remove all oil spills from the engine
3.9
Changing engine oil Danger! Caution when draining hot oil:
Danger of burns! Wear protective gloves! Use suitable tools, e.g. for unscrewing the oil drain plug 1! Change the oil as follows: Park the machine on level ground • Let the engine run until it reaches operating temperature (oil temperature about 80 °C) • Stop the engine Place container for collecting the oil under the engine
+ 80 °C
➥ (minimum capacity: 12 l) ☞ Open oil drain plug 1
OIL Fig. Fig.24: 24: Checking Checkingthe theoiloillevel level
3-14
• Completely drain the oil
1
☞ Screw in oil drain plug 1 and fill in engine oil • See “Engine/machine fluids” for the oil type and capacities
