Maintenance and servicing work Workshop “C” every 1500 s/h once a year
“B” 2nd Inspection1 every 500 s/h
“A” 1st Inspection1 at 100 s/h
Maintenance work (once a day)
Every 20 s/h
Operator/driver
Delivery inspection
Work description
Workshop
Leakage check ( ): Check for tightness, leaks and chafing: pipes, flexible lines and screw connections. Have rectified by an authorised workshop if necessary. •
Air intake line12 (air filter – engine)
•
Engine lubrication (engine – filter)
•
Fuel lines13
•
Cooling system (engine – hydraulic oil)
•
Steering system9 (flexible lines and steering rams)
•
Hydraulic system (flexible lines14 and rams)
•
Brake system9 (flexible lines and cylinders)
•
Air conditioning system (option) – flexible lines, condenser, dehumidifier
1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14.
3-8
Have the 1st Inspection at 100 service hours and the 2nd Inspection at 500 service hours carried out by an authorised workshop otherwise warranty claims will not be acknowledged Replace filter insert at least every 12 months or 1500 s/h. When working in an acidic environment, replace the filter every 300 s/h! When using biodegradable oil: drain the condensation water in the hydraulic oil tank every 500 s/h, in any case before the cold season. Depending on operation and dust conditions, it may be necessary to replace the fine-dust filter more frequently Replace every 2 years Clean radiator more frequently depending on operation and dust conditions. Make a note of the date the battery is charged Safety part! All maintenance and repair work must be carried out by an authorised workshop See maintenance instructions for aggressive media, order no. 1000108296 Observe the manufacturer’s indications for lubrication of the attachment! In order to avoid engine damage, have air intake lines with cracks and chafe marks immediately replaced by an authorised workshop Replace flexible fuel leak oil lines every 2 years (plastic lines) Replace flexible lines every 6 years (DIN 20066 part 5)
