Specifications 2.6
Brakes
Service brake Wheel loader models 349-00/349-01 Design
Foot-operated hydrostatic disc brake
Location
Input shaft – front axle input
Effect
On both axles via cardan shaft
Parking brake Wheel loader models 349-00/349-01
2.7
Design
Manual mechanical disc brake
Location
Input shaft – front axle input
Steering system Wheel loader models 349-00/349-01 Design Steering mode Assemblies Displacement (servostat) Steering pressure Hydraulic pump (gear pump) displacement
Serv-HB 34900/01 – Edition 1.0 * 34901_0210_Technische Daten.fm
Hydrostatic 4 wheel steering with emergency steering features 4 wheel steering/front axle steering (option) Hydraulic pump, steering unit with priority valve, one steering ram per axle, automatic synchronisation in final positions (left and right) 60 cm³/rev / steering wheel rotation 180 bar (2560 psi) 20 cm3/rev (1.22 cu. in./rev)
2-5
