Specifications 2.4
Drive
Variable displacement pump Wheel loader models 349-00/349-01 Design Displacement Max. operating pressure Starting engine speed Control Driving direction Inching Pushing power
Automotive, infinitely variable hydrostatic axial-piston gearbox 0 – 40 cm ³/rev 460 bar 1250 – 1350 rpm at 50 bar HP Speed-sensitive, hydraulic displacement adjustment with pressure cutoff Electrohydraulic control Inching valve via brake/inching pedal 26.0 kN1/28 kN2
Boost pump integrated in variable displacement pump Design Displacement Charging/boost pressure 1. 2.
Serv-HB 34900/01 – Edition 1.0 * 34901_0210_Technische Daten.fm
Internal gear pump 11.6 cm³/rev 25 – 30 bar at 2800 rpm
Model 349-00 with tyres 10.5-18 Model 349-01 with tyres 12.0-18
2-3
