Cab overview, use, operation Variable displacement motor number Seen on lower side of machine. The type label (arrow) is located on the housing of the variable displacement motor (rear axle).
Fig. 7:
Variable displacement motor type label
Number of transfer gearbox Seen on lower side of machine. The type label (arrow) is located on the housing of the transfer gearbox (rear axle).
Fig. 8:
Gearbox type label
Front or rear axle number Seen on lower side of machine. The type label is located on the axle support (arrow). ➥ Rear axle (on the left in driving direction)
Fig. 9:
Rear axle and gearbox type label
