Electrical System – 5000 Parameters Order number 222995-040
Date 2005-10-28
Valid from serial number 723984-
T-code 677, 678, 679
Parameter no. (range 16-19) Independent variable: #0 is the option designation
16 - 0 - 1
Independent variable value (range 0-63) 0= no option has been activated for this parameter 1 to 63 = Pre-programmed option number. See separate table.)
SETTING THE OPTIONAL FUNCTION
Independent variable: #1, #2, #3 & #4 contain the optional function valu
16 - 1- 1
Independent variable value (the range depends on the function referred The value depends on the option and independent variable selected. See separate table CONFIGURING THE OPTIONAL FUNCTION
Fig. 1 Summary – option parameter
Changing configurable optional functions In order to activate a configurable optional function, it must first be assigned a parameter from #16 to #19. This is done by changing independent variable #0 to the pre-programmed option number. Once this has been done, the independent variable for the option must be configured. This is done by changing the values for independent variables #1, #2, #3 and #4. • Ensure the truck is in parameter mode.
The parameter symbol is lit. • Select parameter #16, #17, #18 or #19 using [L1]. Independent variable #0 is displayed The independent variable value is displayed after 1 second. The value “0” means that an optional function has not been assigned to this parameter, and the speed control L1 in this case displays the next parameter if you continue to activate it. • Press the horn button S18.
The parameter symbol flashes. • Enter the independent variable value #0 by repeatedly operating the speed control L1 in either direction. See Table 3: • Press the S18 horn button once to confirm the new setting. © TIEE SARL
Service Manual
7PM18, 7PM20, 7PML20
14- 41
