Electrical System – 5000 Parameters T-code 677, 678, 679
Valid from serial number 723984-
Date 2005-10-28
Order number 222995-040
The parameter symbol is lit (i.e. stops flashing).
• Switch off the truck by pressing
on the keypad.
The non-configurable option is now activated. • Check that the function works correctly before the truck is put back in operation. P
Sub-parameter no.
Function name
Function ON
Function OFF
Basic setting
Table 2: Parameter #15 Non-configurable option Value
Note!
1
"Turtle" function
1
0
0
2 to 9
For future use
-
-
-
Parameter #16 to 19 configurable optional functions Parameter no. #16, #17, #18 & #19 can be adjusted to activate up to a maximum of 4 pre-programmed functions and configure these to suit optional equipment or customisation of the truck. See Table 2 on page 40. These are thus called the configurable optional functions. • Each parameter can be programmed to cover a specific optional function. • Each optional function can have up to 4 independent variables associated with it. • Each independent variable has a value you can change to configure the function.
14- 40
Service Manual
7PM18, 7PM20, 7PML20
© TIEE SARL
