Electrical System – 5000 Parameters Order number 222995-040
Date 2005-10-28
Valid from serial number 723984-
T-code 677, 678, 679
Option parameters WARNING ! Do not try to change these parameter unless you have specific knowledge of the truck options or truck modifications. This service manual only covers the truck’s standard equipment. Specially modified trucks may require you to have access to particular service information. Incorrect adjustment of option parameters may result in incorrect function.
General Parameters #15 to #19 have been reserved in the truck control system for extra options and/or specific product modifications. These parameters are normally configured by the manufacturer on modification or customisation of the truck. It is recommended that the parameter settings be loaded up from the truck when carrying out any modification. If, for example, the main electronic card [A2] must be replaced, the original parameter settings can then be simply transferred to the new card, which ensures that all the special options function correctly.
Parameter #15 Non-configurable options Up to 16 so-called sub-parameters are stored under parameter #15. Their status is either ON or OFF and they do not require any other adjustments. They are therefore called non-configurable options.
Changing non-configurable options • Ensure the truck is in parameter mode.
The parameter symbol is lit. • Select parameter #15 using [L1]. The first set-up of sub-parameters is displayed The next set-up of sub-parameters is displayed if you continue to activate the speed control L1. Ensure that only the relevant sub-parameters are displayed. The value of the sub-parameters is displayed after 1 second. • Press the horn button S18.
The parameter symbol flashes.
.
• Enter the sub-parameter value by repeatedly operating the speed control L1 in either direction. See Table 2: for more information. • Press the S18 horn button once to confirm the new setting.
© TIEE SARL
Service Manual
7PM18, 7PM20, 7PML20
14- 39
