Electrical System – 5000 Error codes T-code 677, 678, 679
14- 28
Valid from serial number 723984-
Date 2005-10-28
Order number 222995-040
Code
C90 (Option)
Description
Extra I/0 (0) CAN communication error
Possible error cause
Data from extra I/0 box /(0) not being received by [A2]/ Check the CAN-bus cable and the connections. [A2] Restart the truck.
Code
C91 (Option)
Description
Extra I/0 (1) CAN communication error
Possible error cause
Data from extra I/0 box /(1) not being received by [A2]/ Check the CAN-bus cable and the connections. [A2] Restart the truck.
Code
C92 (Option)
Description
Configuration error Extra I/0 (0)
Possible error cause
Incorrect setting of options in the extra I/0 box (0) Check the outputs’ allocation on the I/0 expansion box (0)
Code
C93 (Option)
Description
Configuration error Extra I/0 (1)
Possible error cause
Incorrect setting of options in the extra I/0 box (1) Check the outputs’ allocation on the I/0 expansion box (1)
Code
E101
Description
Travel regulator does not correspond with the type of truck
Possible error cause
Incorrect travel regulator or electronic card has been installed. The truck has a built-in control function that checks to ensure the wrong combination of travel regulator and electronic card has not been installed.
Action
Check travel regulator and electronic card.
Service Manual
7PM18, 7PM20, 7PML20
