Electric drive motor – 1760 Component parts T-code 677, 678, 679
Valid from serial number 723984-
Pos
Description
12
Stator
13
Cable
14
Cable
15
Bearing shield
16
Screw
17
Seal
18
Bearing
19
Washer
20
Locking ring
21
Locking ring
Date 2005-10-28
Order number 222995-040
Note
M6x25
9.1.1 Dismantling/assembling of motor from truck • Switch off the truck and pull out the battery plug. • Remove the covers for the motor compartment. • Release the cables for the motor and tiller arm. • Unscrew the four nuts for the attachment of the motor to the drive gear. • Loosen the cables for the key switch and emergency switch. Pull out all the cables from the cover’s cable duct. • Loosen the cover over the motor compartment and the tiller arm’s mounting from the motor. Remove the cover over the motor compartment together with the tiller arm. • Carefully lift the motor straight up, without damaging the sealing surfaces to the drive gear and place the motor on a clean surface. • Protect the drive gear from impurities by covering over its opening in an appropriate manner, e.g. with a piece of plastic. The requisite service and repair of the motor can now be carried out.
