Preventive maintenance – P2 Maintenance schedule T-code 677, 678, 679
Valid from serial number 723984-
Date 2005-10-28
Order number 222995-040
I: Inspect, rectify and change if necessary. T: Tighten. C: Clean. L: Lubricate. M: Control measurement, rectify if necessary
Pos. No.
Work to carry out Interval in hours may vary due to application Interval in days/weeks/months may vary due to application
5
20
80
500
1000
3000
1d
1w
1m
6m
12m
36m
6100
Hydraulic system
6100.1
Check hoses and connections for wear
I
6100.2
Check hoses for wear and damage
I
6100.3
Check the oil tank for cracks, leakage and damaged mountings
I
6100.4
Check that the oil level is correct
6100.5
Change the oil and clean the filter
6600.
Lift cylinder
6600.1
Check for leakage
I
6600.2
Check the mountings
I
6680
Power Trak
6680.1
Check if there is any damage or cracks on the PowerTrak spring
6680.2
Grease in the contact pressure spring’s guides
I L
L5
I C/L
1 = The connections are re-tightened for the first time after 80 h, and then every 1000 h/12 months. 2 = The attachment bolts are re-tightened after 80 h/ 1 month to 45 Nm. 3 = Check for leakage in conjunction with the first oil change. 4 = The oil is changed for the first time after 80 h/1 month, and then every 3000 h/36 months 5 = The oil is changed and the filter cleaned for the first time after 80 h/ 1 month, and then every 1000 h/12 months. 6 = If the truck goes into a refrigerated environment or other harsh environment, the point is addressed at more frequent intervals. When points with higher hour intervals are carried out the points with lower hour intervals should also be carried out unless otherwise specified above.
4- 4
Service Manual
7PM18, 7PM20, 7PML20
