Control/computer equipment – 8700 Installation Order number 222995-040
Date 2005-10-28
Valid from serial number 723984-
T-code 677, 678, 679
Double-click on the LPT port to be changed, and select the Port Settings tab. Check the "Use any Interrupt assigned to the port" option and click on OK.
The software application is supplied on a CD or via a network. Start installation by running X:\SETUP.EXE, where X:\ is the drive on which the installation application can be found. Then follow the on-screen instructions.
18.12.3 Installation on a PC with Windows NT The software application is supplied on a CD or via a network. Start installation by running X:\SETUP.EXE, where X:\ is the drive on which the installation application can be found. Then follow the on-screen instructions.
18.12.4 In case of communication problems with CAN Make sure the computer settings for the printer port in the BIOS Setup are as follows: Port address:0378 IRQ:7 Mode:Output only For detailed information on how to change the Setup settings, refer to the User's Guide supplied with the computer.
© TIEE SARL
Service Manual
7PM18, 7PM20, 7PML20
18- 21
