Control/computer equipment – 8700 Other menu functions T-code 677, 678, 679
Valid from serial number 723984-
Date 2005-10-28
Order number 222995-040
• “Voltage analog input 2, pin13”- The measured DC input signal (1) from the steering potentiometer. • “Current” - the measured current supplied to the steer servo motor in Ampere • “Actual velocity” -The measured rotational speed of the steer servo motor shaft in r.p.m.
18.10 Other menu functions 18.10.1 Save to file The truck parameters can be saved in the PC for downloading at a later date. Select <File | Save to file | Parameters >. All parameters in the nodes which are connected to the bus will be scanned in and saved in a file. If only the hour meters are needed, select <File | Save to file | Hour meters >.
18.10.2 Download from file A set of parameters can be downloaded from the PC to the truck. Select <File | Load from file | Parameters >. The parameters in the file will be copied to the nodes connected to the bus. If only the hour meter settings are needed, select <File | Load from file | Hour meters >.
18.10.3 Reset CAN adapter If problems should occur when resetting the CAN adapter connected to the PC, this can normally be done manually by making sure that the adapter is supplied with voltage and then selecting <Nodes | Reset CPC-PP >.
18.10.4 Delete error code log To delete the truck’s error code log, start the truck in parameter mode and then select < Tools | Erase error log >.
18.10.5 Reset hour meter To reset the truck’s hour meter, start the truck in drive mode and then select < Tools | Reset hour meters >.
18.10.6 Read error code log To show the truck’s error code log, select < Tools | Read error log >.
18- 14
Service Manual
7PM18, 7PM20, 7PML20
