Control/computer equipment – 8700 Connection function T-code 677, 678, 679
Valid from serial number 723984-
Date 2005-10-28
Order number 222995-040
18.3.4 Tool buttons and menu bar The tool button bar allows direct access to the program’s most common functions. The menu bar allows access to all the program functions. Explanations of each menu bar item are given in the relevant section. Search for units
Disconnect Download from PC
Truck report
Parameters Diagnostics Information
Exit
Fig. 4 Tool button bar
18.3.5 Information window The right section of the main window contains a status window where different messages are shown. To see previous messages, use the scroll arrows in the right margin.
18.3.6 Status bar There is a status bar at the bottom of the main window, which shows variable status when the program is run. REC
MACHINE
The following are shown from the left: Help text "pop-up" via the mouse cursor, connected/not connected to network, truck type connected, initiation result of CAN interface and the present time.
18.4 Connection function To connect the PC the network, select the Scan units function. This can be done with the menu <Nodes | Scan units> or with the tool button [Scan nodes]. This should also be done when the truck is supplied with voltage and in normal drive mode. The program will now run a check and installation of the CAN interface. A diagnosis will also be carried out to check which units are connected in the system. The result of this diagnosis is shown in the Node window.
18- 4
Service Manual
7PM18, 7PM20, 7PML20
