18.3.3 Icons Icon
Description Node OK is shown when contact is made with a node and no errors have been reported. Node not connected is shown when there is no contact with a node in the network. Node not OK is shown when an error has been reported by a node. Click on node to obtain more information. Program version is shown when information is available on which software is installed. Click to obtain more information. Information is shown when a node has information on, for example, error codes. Truck report GB ”Truck report function” on page 8. Parameters is shown when a node has information on a parameter. Diagnostics
