Electrical System – 5000 Parameters Order number 222995-040
Date 2005-10-28
Valid from serial number 723984-
T-code 677, 678, 679
• Select the programming command from Table 5:
Table 5: Programming command - expanded keypad Progamming
Function
Notes
Reset to factory settings
Block 1 - 9 is deactivated. Original PIN codes reset as per Table 6:: B= Block no. 0 - 9
Press “2” + B +
PIN codes in the block can be used
B= Block no. 0 - 9
Press “3” + B +
PIN codes in the block cannot be used Programming a new PIN code
B= Block no. 0 - 9 F= Driver profile no. 0-9 NNNN = PIN code
Press “1” +
Press “4” + B + F + NNNN +
• Switch off the truck by pressing
on the keypad.
The expanded keypad programming is now complete Parameter #39 must be set with the value 5, 6, 7 or 8 for the new PIN codes to be valid. Carry out a practical test by logging in using some of the new PIN codes. It is important to establish that the correct driver profile has been activated when a certain PIN code has been entered, especially if a specific driver profile has been set for a specific application/goods handling. Table 6: shows the PIN codes available as standard in the program. These can be activated for use or changed according to the driver’s wishes. One or more of these blocks can be activated. A driver profile is activated, on normal login, by all PIN codes whose block no. is activated. The truck program does not approve login using the PIN code “0000”. Service personnel should keep notes on activated blocks, changed PIN codes and specially-set driver profiles. NOTE! Resetting the expanded keypad does NOT affect the driver profile settings.
© TIEE SARL
Service Manual
7PM18, 7PM20, 7PML20
14- 51
