Electrical System – 5000 Parameters T-code 677, 678, 679
Valid from serial number 723984-
Date 2005-10-28
Order number 222995-040
Login method and driver parameter access This parameter determines which function is to be used for login and whether the operator can adjust the driver parameter settings. • Value 1 – Key switch fitted – Driver parameters accessible (without CAN service key). • Value 2 – Key switch fitted – Driver parameters NOT accessible (without CAN service key). • Value 3 – Keypad (Standard 10 PIN code)- Driver parameters accessible (without CAN service key) NB! this is the original setting. • Value 4 – Keypad (Standard 10 PIN code)- Driver parameters NOT accessible (without CAN service key). • Value 5 – Expanded keypad (100 PIN code)- Driver parameters accessible (without CAN service key) • Value 6 – Expanded keypad (100 PIN code)- Driver parameters NOT accessible (without CAN service key) • Value 7 – Expanded keypad (100 PIN code) + TLS- Driver parameters accessible (without CAN service key) • Value 8 – Expanded keypad (100 PIN code) + TLS- Driver parameters NOT accessible (without CAN service key)
Expanded keypad - General The truck can contain a maximum of 10 individual driver profiles. The expanded keypad function thus allows you to assign a maximum of 10 PIN codes for each of the driver profiles. This allows you to manage a maximum of 100 unique PIN codes. If the expanded keypad function is activated, the standard management of PIN codes normally accessible via parameter #10 is set aside.
Expanded keypad - Programming A number of PIN codes can be made accessible by activating the socalled block. Block no. 0 is activated as standard. This means that 3 different driver profiles are available from the start. Activation of other blocks means that all PIN codes for the block are accessible (See Table 6:). If all 10 blocks are activated, there will be 10 PIN codes available for the driver profile. The truck program stores a standard list of PIN codes as per Table 6: These PIN codes can be changed to any value, but you should avoid the same PIN code in different driver profiles. To start programming the expanded keypad: • Connect an appropriate CAN service key to X41 • Enter code 341671 and press 14- 50
Service Manual
on the keypad.
7PM18, 7PM20, 7PML20
