Emission Control System (ECS) Cleaning Diesel Exhaust Fluid (DEF) Tank Spilled DEF, if left to dry or if only wiped away with a cloth, leaves a white residue. Improperly cleaned DEF spill can interfere with diagnosis of Selective Catalytic Reduction (SCR) system leakage problems. If foreign material or fluid has been added to the DEF tank, drain the DEF tank, flush, and fill with new DEF. If DEF quality is in question, pull a sample out of the DEF tank and place into a clear container. DEF should be crystal clear with a light ammonia smell. If DEF appears cloudy, has a colored tint or has a profound ammonia smell, it is likely not within specification. DEF in this condition should not be used. Remove quick connector from Top and rotate down the level indicator tube and drain or siphon bad DEF from DEF tank or remove quick connector from bottom to drain or siphon DEF from tank.
Avoid contact with eyes. In case of contact, immediately flush eyes with large amounts of water for a minimum of 15 minutes. Refer Material safety data sheet (MSDS) provided by DEF supplier for additional information.
If DEF is spilled or contacts any surface other than the storage tank, immediately clean the surface with clear water. DEF is corrosive to painted and unpainted metallic surfaces and can distort some plastic and rubber components.
NOTE: Cleaning should take place with DEF tank installed. Clean DEF tank with new DEF 1. Remove the quick connector to drain the DEF from DEF tank. 2. If any contamination is suspected, thoroughly flush DEF tank with distilled water and again with ample amount of DEF. NOTE: Repeat the above step 2 - 3 times until DEF tank has been cleaned. 1. Change DEF tank filler neck filter (A). 2. Connect quick connector in DEF tank, if removed. 3. Fill DEF tank with new DEF. 4. Check DEF concentration with (if refractometer is available)
DEF
refractometer A
If DEF is not within specification, does not appear clear, or does not have a slight ammonia smell, contact your authorized dealer. Disposal of Diesel Exhaust Fluid (DEF) Although there is little issue with minor spillage of DEF on the ground, large amounts of DEF should be contained. If large spills occur, contact local environmental authorities for assistance with clean-up. If a substantial quantity of DEF is not within specification, contact the DEF supplier for assistance with disposal. Do not dump substantial quantities of DEF onto the ground or send DEF to waste water treatment facilities.
8000 Series, Models - 8090/8100 4WD CAB TIER-4 Final
