Cooling System Thresh Guard for Radiator (A) A wiremesh thresh guard is provided, at the front of the radiator which restricts thresh and other coarse particles from entering into Radiator fins. It thus prolongs the duration between two cleanings of radiator. To clean thresh guard, Open the hood. Then remove the thresh guard by pulling it away from the tractor. Clean it thoroughly. Re-assemble the thresh guard after cleaning.
A D
B Thresh Guard for Condensor (B)
C
A wiremesh thresh guard is provided, at the front of the condensor. To clean thresh guard, Open the hood. Remove the condensor thresh guard by pulling it away from the tractor. Clean it thoroughly. Re-assemble the thresh guard after cleaning.
Extra care while operation in CHAFFY conditions.
Thresh Guard for Transmission Oil Cooler (C) A wiremesh thresh guard is provided, at the front of the transmission oil cooler. To clean thresh guard, Open the hood. Remove the wing nuts (D). Remove the oil cooler thresh guard by pulling it away from the tractor. Clean it thoroughly. Re-assemble the thresh guard after cleaning. F Thresh Guard for Fuel Cooler (E)
E
A wiremesh thresh guard is provided, at the front of the fuel cooler. To clean thresh guard, Open the hood. Remove the wing nut (F). Remove the fuel cooler thresh guard by pulling it away from the tractor. Clean it thoroughly. Re-assemble the thresh guard after cleaning. Sealings (G) Side Sealing brushes (G) needs to be checked after 600 hrs of operation or two years from date of purchase whichever is earlier and needs to be replaced if required for better sealing.
8000 Series, Models - 8090/8100 4WD CAB TIER-4 Final
G
87
