Three Point Linkage Adjustable Lift Rods Use turn handle (A) on the adjustable lift rod to raise or lower the Telescopic Lower Link for side-to-side leveling of implement with respect to ground. 1. Raise lift rod turn handle (A) out of locking tab (B). 2. Rotate turn handle (A) clockwise to raise the lower link or anticlockwise for lowering. 3. After adjustment, make sure to engage handle (A) with locking tab (B). Always transport the implement with turn handle in this position.
A B
Locked
Unlocked
Lateral Stabilizers These are provided for adjustment of width between two lower links according to varying implement spans. These enable to keep the implement in either FIXED or FLOATING position. Placing the locating pin in (C) position shall keep the stabilizer and implement in “Fixed” position. Placing the locating pin in (D) position shall keep the stabilizer and implement in “Float” position.
D
C
We recommend to use the fixed position while transporting the implement.
