Mahindra Tractor‘8000’ Series 8090 8100 4WD CABIN TIER-4 FINAL Operator's Manual - PDF DOWNLOAD

Page 51

Controls Range Shift Lever This lever is located on RH side of operator’s seat. This lever has four positions as follows: 1. High

– for High speed range

2. Medium

– for Intermediate speed range

3. Low

– for Low speed range

Tractor Front

4. Neutral This lever enables 3 different speed options for every Speed Gear selection. The lever can be engaged as follows. 1. Depress Clutch completely.

pedal

and

stop

tractor

motion

2. Choose H, M or L speed range to match work application. 3. Release clutch pedal gradually. Refer chart for road speed of tractor in different positions.

Never shift Range shift lever while the tractor is in motion.

Speed Shift Lever This lever is located on R.H side of operator’s seat. This lever has five positions.

Tractor Front

This lever enables 4 different speed options within a particular “Range Gear” selection. The road speed increases in higher gears. 1. Depress Clutch pedal completely. 2. Choose any one gear from 1 to 4 to match work application. 3. Release clutch pedal gradually. The gears can be shifted on-the-go. Refer chart for road speed of tractor in different positions.

Gears

50

mph Forward

Reverse

L1

1.8

1.8

L2

2.9

2.9

L3

4.2

4.2

L4

5.9

6.0

M1

3.4

3.4

M2

5.3

5.4

M3

7.8

7.8

M4

11.0

11.1

H1

6.5

6.6

H2

10.3

10.4

H3

15.1

15.1

H4

21.3

21.4 8000 Series, Models - 8090/8100 4WD CAB TIER-4 Final
